TYPICAL SPECIFICATION

Supply and install the PRM Series high-impact thermoplastic Running Man Exit Signs. The sign shall operate with universal 120 to 347 VAC input and provide a minimum of 90 minutes of emergency illumination upon AC failure. The face shall be illuminated by an ultra-bright LED light source. The unit shall be field-configurable for single or double-face applications and suitable for wall, end, or ceiling mount. The sign shall be CSA C22.2 No.141-15 certified, C860 listed, and ICES-005 compliant.

CONSTRUCTION

• Material: Precision injection-molded, engineering-grade thermoplastic.

• Durability: 5VA flame-retardant, high-impact resistant housing in white finish.

• Compliance: Fully RoHS compliant and UL Listed for damp locations.

ELECTRICAL

• Input: Universal 120-347Vac, 50/60Hz.

• Efficiency: Ultra-low power consumption (1.9W) with a current-limiting charger to minimize operating costs.

• Protection: Integrated short-circuit protection and regulated charge voltage to ensure stable performance across varying line voltages.

• Battery Safety: Features AC Reset and Low Voltage Disconnect (LVD) to prevent deep discharge damage.

• Battery Type: 3.6V AA 500mAh long-life, maintenance-free, rechargeable NiCd battery.

LISTINGS & COMPLIANCE

Certifications: UL damp location listed (0°C to 50°C/32°F to 122°F).

Performance: C860 listed for energy efficiency.

Canadian Standards: Listed and labeled to comply with CSA C22.2 No.141-15.
